Nakamura Stainless, located in Pulau Ujong, Singapore, is a top manufacturer and supplier of high-quality stainless steel components, including stainless steel 316Ti flanges. These flanges are designed for high-temperature and corrosive environments where long-term structural stability and corrosion resistance are crucial. Stainless steel 316Ti is a titanium-stabilized version of 316. It prevents carbide precipitation during welding or heat exposure. Nakamura Stainless ensures precise manufacturing and strict quality control, making their 316Ti flanges a dependable choice for chemical processing, marine environments, and high-temperature piping systems.
Stainless steel 316Ti flanges contain 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a small amount of titanium. The titanium content stabilizes the alloy against sensitization and intergranular corrosion during welding and high-temperature use. These flanges typically provide tensile strength between 500 and 750 megapascals and maintain mechanical integrity at temperatures up to 870°C. The molybdenum increases resistance to pitting and crevice corrosion, especially in chloride-rich conditions.
| Specifications | ASTM A182 / ASME SA182 |
| Size | 1/8″ NB TO 48″ NB |
| Standards | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Grades | S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 |
| ELEMENT | MIN | MAX |
|---|---|---|
| C | – | 0.08 |
| Si | – | 0.75 |
| Mn | – | 2 |
| P | – | 0.45 |
| S | – | 0.03 |
| Cr | 16 | 18 |
| Mo | 2 | 3 |
| N | – | 0.1 |
| Fe | Balance | |
| Ni | 10 | 14 |
| Ti | 5x%(C+N) | |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We offers the best quality Stainless Steel 30TI flanges of superior quality test for best products and performance at an international standards level with due testing and full specification. Being a certified supplier, we certify every batch based on traceable documents. To make the modern products with no corrosion, robust, and quality mechanical properties to give you extra value, we used the modern world’s technology at a stringent and tight quality-control measure. Nakamura Stainless commits to deliver the highest level of flanges that could ensure functionality and safety.
Featuring internal threads for easy attachment to pipes with matching threads, these flanges are typically available from 1/2″ to 6″. Their titanium content enhances corrosion resistance, particularly in aggressive chemical environments
Designed for high-pressure systems, these flanges are inserted into a socket and welded in place. They come in sizes from 1″ to 24″ and offer robust corrosion resistance due to the 316Ti alloy’s resistance to oxidation and chloride stress.
These flanges are used with a loose backing flange and provide a smooth, corrosion-resistant surface for easy alignment and maintenance. They are available in sizes from 1″ to 24″ and are highly resistant to rust and corrosion, suitable for various industries.
Stainless steel 316Ti flanges are commonly used in industries that need strong, corrosion-resistant components that can withstand high temperatures. Common applications include heat exchangers, pressure vessels, marine piping, chemical processing systems, and flue gas scrubbers. Their resistance to oxidation, acid attack, and high-temperature scaling makes them suitable for harsh environments. These flanges provide secure, long-lasting connections in critical systems, offering both performance and reliability in demanding operating conditions.
