Nakamura Stainless, a top-notch manufacturer and supplier based in Pulau Ujong, Singapore, is well-known for delivering high-quality stainless steel products that adhere to global standards. Among their extensive range, **Stainless Steel 310S Pipes** stand out for their remarkable resistance to high temperatures, oxidation, and corrosion. Built to thrive in tough environments, these pipes blend durability with outstanding mechanical strength. Nakamura Stainless prides itself on precision engineering, consistent quality, and dependable performance, making Stainless Steel 310S Pipes a go-to choice for industries that demand stability and efficiency even in extreme heat and harsh conditions.
These pipes are primarily made up of 24–26% chromium, 19–22% nickel, low carbon (≤0.08%), and a balanced mix of iron, along with trace amounts of manganese, silicon, and phosphorus. The high levels of chromium and nickel give them excellent resistance to oxidation and scaling at temperatures reaching up to 1100°C. On the mechanical side, these pipes boast a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of up to 40%. Their low carbon content minimizes carbide precipitation during welding, which enhances their fabricability, strength retention, and long-lasting performance in high-temperature settings.
| Thickness | 0.5mm-100mm | ||||||
| Outer diameter | 10mm, 25.4mm, 38.1mm, 50.8mm, 100mm, 250mm, 300mm, 350mm, etc | ||||||
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | ||||||
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | ||||||
| Finish | Hot rolled (HR), Cold rolled Tube (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) | ||||||
| Form | Round tube Square tube Rectangular tube etc. | ||||||
Grade | Ni | Mn | P | C | S | Si | Cr | Mo | N | |
310S | min. | 8.0 | – | – | – | – | – | 18.0 | – | – |
max. | 10.5 | 2.0 | 0.045 | 0.08 | 0.030 | 0.75 | 20.0 | |||
Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
310S | 515 | 40 | 205 | 92 | 201 |
Contact us to get a quick quote for your requirement.
We tests its pipes of Stainless Steel 310S Pipe and provides certification for these, ensuring excellent performance and durability. Every pipe goes through tough testing with respect to composition, mechanical properties, dimensions, and pressure tests. Our certificate confirms the same to international standards, thereby delivering high-quality, reliable products in every single unit.
Stainless 310S Square Pipes are square-shaped pipes made from 310S stainless steel, offering high-temperature resistance, durability, and corrosion resistance, ideal for structural and industrial applications in harsh environments.
SS 310S Seamless Pipes are pipes made from 310S stainless steel without welded seams, providing excellent high-temperature resistance, strength, and durability for demanding industrial and high-heat applications.
Stainless Steel 310S ERW Pipes are electric resistance welded pipes made from 310S stainless steel, offering high-temperature resistance and durability, ideal for industrial applications and environments with elevated temperatures.
SS 310S LSAW Pipes are longitudinally submerged arc welded pipes made from 310S stainless steel, providing high-temperature resistance, strength, and durability for use in high-pressure and industrial applications.
Stainless Steel 310S Round Pipes are cylindrical pipes made from 310S stainless steel, known for high-temperature resistance, corrosion resistance, and durability, making them suitable for industrial and high-heat applications.
Stainless Steel 310S Welded Pipes are made from 310S stainless steel and joined by welding, offering excellent high-temperature resistance, strength, and durability for various demanding industrial and high-heat applications.
Stainless Steel 310S Pipes find their place in various industries where high-temperature resistance and durability are essential. They’re commonly used in furnace components, heat exchangers, kilns, and boiler tubes. The petrochemical and power generation sectors depend on them for transporting hot gases and corrosive fluids. In refineries and thermal processing plants, they deliver reliable performance even under constant exposure to heat and oxidation. Their corrosion resistance also makes them ideal for marine and chemical applications, while their structural integrity ensures they are a trusted material for construction projects that require strength in elevated temperature conditions.
