Nakamura Stainless, a well-respected manufacturer and supplier based in Pulau Ujong, Singapore, has built a solid reputation for providing top-notch stainless steel products that meet international standards. Among their diverse offerings, **Stainless Steel 304/304L Sheet and Plates** stand out for their remarkable corrosion resistance, strength, and weldability. These sheets and plates are crafted to perform reliably across a variety of industrial settings, from chemical processing to structural applications. With a focus on precision manufacturing and rigorous quality control, Nakamura Stainless guarantees that their Stainless Steel 304/304L Sheet and Plates deliver durability, efficiency, and long-lasting service in even the most demanding sectors.
The composition of Stainless Steel 304/304L Sheet and Plates includes 18–20% chromium and 8–12% nickel, along with a low carbon content (≤0.03% in 304L) to reduce carbide precipitation during welding. This dual-grade makeup ensures excellent corrosion resistance, particularly in reducing environments, while also maintaining impressive toughness. On the mechanical side, they boast a tensile strength of around 515 MPa, a yield strength of 205 MPa (170 MPa for 304L), and an elongation of about 40%. These characteristics provide outstanding ductility, weldability, and structural stability, making them perfect for critical industrial and fabrication applications.
Stainless Steel Sheets and Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
| C | Mn | Si | P | S | Cr | Ni | N | |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.07max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 10.5 | — |
| 304L | 0.03max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 12.0 | 0.10 max |
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 304 | 75 | 30 | 40 | 201 | 92 |
| 304L | 70 | 25 | 40 | 201 | 92 |
Contact us to get a quick quote for your requirement.
This type of stainless steel is known for its good corrosion resistance. The thickness of this type of stainless steel ranges from 3mm to 100mm. The sheets and plates are available in sizes up to 1500mm x 3000mm. Suitable for structural applications and industrial uses.
Offering great corrosion resistance, 304L cold-rolled sheets and plates are well known for smooth finish. These are available in thicknesses of 0.5mm up to 12mm, standard sizes up to 1500mm x 3000mm. They are ideal for applications requiring high-quality surface.
With superior corrosion resistance, 304L chequered sheets and plates are designed for anti-slip applications. They typically come in 2mm to 6mm thicknesses and sizes up to 1500mm x 3000mm. They are commonly used in flooring and stair treads.
Featuring excellent corrosion resistance, these hole-perforated sheets and plates come in different hole patterns, size, and thickness with a specified range of 0.5mm to 6mm, standard dimension up to 1500mm x 3000mm, suitable for filtration and decorative uses.
304 shim sheets and plates have good corrosion resistance. They can be as thin as 0.1mm. Standard sizes can go up to 1500mm x 3000mm. These are used in machinery for accurate spacing and adjustment.
304 polished sheets and plates offer excellent corrosion resistance and a high-gloss finish. Thicknesses from 0.5mm to 12mm, and sizes up to 1500mm x 3000mm. Aesthetic and architectural applications.
Nakamura Stainless aims at making the purchase process hassle-free for its clients by offering detailed documentation of excellent quality Stainless Steel 304/304L Sheets and Plates. These include critical commercial invoices, packing lists, fumigation certificates, heat treatment charts, quality assurance plans, and NABL-approved lab test reports, which give the authenticity and premium quality to our products. We also offer Stainless Steel 304/304L Sheets and Plates with Test Certificate like EN 10204 3.1b, PMI Test Certificate, radiography test reports of 100%, and third-party inspection. It shows us focused on satisfaction to our valued customers and also hard work.
Stainless Steel 304/304L Sheet and Plates are widely utilized in industries that demand durability, corrosion resistance, and ease of fabrication. They find extensive use in chemical processing, oil and gas, food and beverage, and pharmaceutical sectors due to their hygienic properties. Their excellent weldability makes them ideal for tanks, piping systems, and pressure vessels. Additionally, they are employed in marine applications, water treatment facilities, architectural structures, and general engineering projects. These sheets and plates ensure long-lasting performance, providing reliability in both moderate and harsh operating conditions.
