Nakamura Stainless stands out as a top manufacturer and supplier in Pulau Ujong, Singapore, offering high-quality stainless steel solutions that meet international standards. One of their standout products, **Stainless Steel 253MA Sheet and Plates**, is highly regarded for its remarkable resistance to oxidation, impressive strength at high temperatures, and extended service life. These sheets and plates are specifically engineered for tough environments, blending durability with exceptional performance in heat-intensive applications. With a strong focus on quality, prompt delivery, and customer satisfaction, Nakamura Stainless is dedicated to supporting various industries, including construction, petrochemical, and manufacturing, with dependable stainless steel products.
**Stainless Steel 253MA Sheet and Plates** are made from iron combined with 20–22% chromium, 10–12% nickel, and trace amounts of nitrogen, silicon, and rare earth elements, all of which boost oxidation resistance and strength at elevated temperatures. Their mechanical properties feature a tensile strength of around 600 MPa, a yield strength of about 310 MPa, and good elongation. These sheets and plates also showcase excellent creep resistance and can handle oxidation up to 1150°C. The well-balanced composition ensures superior toughness, weldability, and formability, making them perfect for both structural and heat-intensive industrial uses.
Stainless Steel Sheets and Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
| Cr | Ni | Si | C | Mn | P | S | N | Ce | Fe | |
|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 20.00 | 10.00 | 1.40 | 0.05 | – | – | – | 0.14 | 0.03 | Balance |
| MAX | 22.00 | 12.00 | 2.00 | 0.10 | 0.80 | 0.04 | 0.03 | 0.20 | 0.08 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Reduction Area,% |
|---|---|---|---|---|
| 253 MA | 87,000 | 45,000 | 40 | 50 |
Contact us to get a quick quote for your requirement.
Hot-rolled stainless steel 253MA sheets are manufactured by a process known as hot rolling at elevated temperatures, ensuring robust and tough materials. Thickness usually ranges between 3mm to 100mm. Excellent resistance to corrosion and oxidation in a high temperature is one of its excellent characteristics.
These stainless steel 253MA cold rolled plates are made at room temperature, giving these plates a smooth finish with very precise dimensions. Thickness is available from 0.3mm up to 3mm and offers high resistance against corrosion. They are ideal for applications wherein tight tolerances and high quality of surface finish can be achieved.
Stainless Steel 253MA Chequered Sheets provide a raised diamond pattern for improved grip and aesthetics. Available in gauges between 3mm and 12mm, these sheets have corrosion resistance properties. The product is widely used in floorings, walkways, and decorative applications.
Stainless Steel 253MA perforated plates offer evenly spread holes, used for ventilation, filtration, and decorative purposes. They offer these plates in various hole sizes, available from 0.5mm to 5mm thickness. They have excellent corrosion resistant and good for applications where they need to allow airflow and drainage.
Stainless Steel 253MA Shim Sheets are thin and precise sheets applied for adjustments and alignment in machinery and structures. They are offered in a variety of thickness from 0.1mm up to 3mm. Their excellent corrosion resistance makes them critical for tight tolerance applications in numerous industries.
Stainless Steel 253MA Polished Plates are buffed to a reflective, mirror-like finish. The plates are available in thicknesses from 0.3mm to 50mm. They are used in architectural, decorative, and high-visibility applications due to their superior corrosion resistance.
Nakamura Stainless prioritizes delivering a seamless customer experience backed up by thorough documentation of the premium-quality Stainless Steel 253MA Sheets and Plates. Essential documents include the commercial invoice, packing list, fumigation certificate, heat treatment chart, quality assurance plan, and NABL-approved lab test report. These documents create authenticity and superior quality of our products that earn the trust of our esteemed clients. Moreover, we offer Stainless Steel 253MA sheets and plates with various test certificates including MTC as per EN 10204/3.1b, PMI Test Certificate, 100% radiography test report and Third-Party Inspection Certificate. These test certificates indicate our customer-centric approach while achieving excellence in every product.
**Stainless Steel 253MA Sheet and Plates** find their place in industries that demand high-temperature performance and oxidation resistance. They’re commonly used in furnace components, heat exchangers, kilns, petrochemical equipment, and power generation plants. Their ability to resist scaling and thermal fatigue makes them ideal for boilers, burners, and combustion chambers. Plus, their strength and toughness in extreme conditions allow for applications in construction frameworks, cement industries, and metallurgical processing, guaranteeing a long service life and reliable performance even in the toughest environments.
